ГОСТ . Элементы штампуемых деталей. Конструкция и размеры

Настоящий стандарт распространяется на типовые элементы (сгиб, отбортовка, выдавка, борт) для придания жесткости штампуемым деталям из листа цветных сплавов толщиной s не более 4 мм с допускаемым утонением материала при штамповке не более 20 %

Название на англ.:

Stamping part elements. Construction and dimensions

Тип документа:

стандарт

Статус документа:

действующий

Число страниц:

34

Дата актуализации текста:

22.03.2010

Дата актуализации описания:

22.03.2010

Дата издания:

01.07.1990

Дата введения в действие:

01.07.1981

Дата последнего изменения:

23.06.2009

Переиздание:

переиздание с изм. 1

Взамен:

ГОСТ

Поправки и изменения:

    Изменение №1 к ГОСТ Изменение №2 к ГОСТ
