Стас Михайлов - Технический райдер - 2011 (стр. 2 )

№	Instrument	Mic, Di-Box	Stands/split	Inserts/split
1	KICK	Shure BETA 91!!!	SMALL	Gate
2	SNARE (Top)	Shure SM 57	TALL	Gate
3	SNARE (Bottom)	Shure Beta 57	SMALL	Gate
4	H-H	Shure SM 81 (condenser)	TALL
5	RACK TOM	Shure Beta 98	CLIPS	Gate
6	FLOOR TOM 1	Shure Beta 98	CLIPS	Gate
7	FLOOR TOM 2	Shure Beta 98	CLIPS	Gate
8	RIDE	Shure SM 81 (condenser)	TALL
9	OH L	Shure SM 81 (condenser)	TALL
10	OH R	Shure SM 81 (condenser)	TALL
11	BASS	DI-BOX
12	EL. Guitar 1	Shure SM 57 (offstage cabinet)
13	AC. Guitar 1	DI-BOX
14	EL. Guitar 2	Shure SM 57 (offstage cabinet)
15	AC. Guitar 2	DI-BOX
16	AC. Guit.3(centre)			Сompressor
17/18	KEY 1 L/R	DI-BOX
19/20	KEY 2 L/R	DI-BOX
21/22	KEY 3 L/R	DI-BOX
23/24	KEY 4 L/R	DI-BOX
25	FOH 1	Return from FOH – AUX 1	Line
26	FOH 2	Return from FOH – AUX 2	Line	Сompressor
27	FOH 3	Return from FOH – AUX 3	Line
28	Talkback FOH	Return Talkback FOH mic
29	Talkback MON	Shure SM 58 with switch
34(30)*	BACK VOX 1	Shure SM 58, Beta 58	TALL
35(31)*	BACK VOX 2	Shure SM 58, Beta 58	TALL
36(32)*	BACK VOX 3	Shure SM 58, Beta 58	TALL
		*(….) – only for MON console
39-43	PERCUSSION	3x Shure SM 57 / 2x Shure SM 81	5xTALL
.
Stereo 1			Stereo 3	“HALL”	(any) Internal
Stereo 2			Stereo 4

AUX SENDS of MONITOR DESK

Aux 1 – Drum wedge (1 MON)	Aux 9 – Back Voc / In-Ear “6” R
Aux 2 – Bass wedge (2 MON)	Aux 10 – Back Voc / In-Ear “7” R
Aux 3 –Key 1 / In-Ear “1”	Aux 11 – “Hall” Internal
Aux 4 – to Key mixer only	Aux 12 – “CUE” (control wedge)
Aux 5 – Guit 1 / In-Ear “3”	Aux 13 – split to Key&Drum mixers
Aux 6 – Guit 2 / In-Ear “4”	Aux 14 – split to Key&Drum mixers
Aux 7 – Back Voc / In-Ear “5, 6, 7” Left	Aux 15 – to Drum mixer only
Aux 8 – Back Voc / In-Ear “5” R	Aux 16 – to Drum mixer only
AUX AUX 13&14 – split and sent to Key&Drum mixers. Master of Key mixer sent to In-Ear “2” (stereo).
Attention!!! Monitor lines 1, 2 and Side-Fills are mixed from FOH console!!!

Powered wedge

Monitor Out (wedge)

Aux 1 MON

Send (stereo) to 2-nd In-Ear from Key-mixer Master L/R Add. M

Kick + Overhead

Aux 13-16 (MON) to Drum mixer

…TO OFFSTAGE EL. GUITARS 1&2 CABINETS
